Debug and Visualize

Retriever debugging should start before a robot backend is involved. Use the same Pipeline source and move through four increasingly concrete views: graph, local stepper, live visualization, and replay artifact.

The Debug Loop

Question	Command	Artifact
Did I wire the graph I intended?	`pixi run docs-tutorial-perception-html`	`artifacts/tutorial_perception.html`
Does Flow logic work in ordinary Python?	`pixi run demo-stepper`	stdout step trace
Does perception work without camera/GUI risk?	`pixi run demo-webcam-detection-mock`	stdout detection events
Does live perception visualize correctly?	`pixi run demo-webcam-detection`	Rerun viewer or stdout fallback
Can I debug the same events again?	`pixi run demo-webcam-record` then `pixi run demo-webcam-replay-rrd`	`logs/perception.rrd`, `logs/perception.mcap`

Render the Graph

pixi run docs-tutorial-perception-html

Open the generated HTML artifact and inspect:

Flow nodes,
input/output ports,
each Flow clock,
each edge sync policy,
feedback edges and fan-in points.

When a robot pipeline feels confusing, this is usually the first artifact to inspect because it shows timing and handoff decisions without requiring a backend.

Step Locally

pixi run demo-stepper
pixi run demo-perception-stepper

The stepper path is useful because it keeps debugging inside ordinary Python:

pipe.validate()

for _ in range(10):
    result = pipe.step(dt=0.1)
    print(result.executed)

pipe.close_stepper()

Use this mode when you want breakpoints inside Flow.step(...), deterministic local state changes, or a short failing case before launching multiprocessing or dora.

Visualize Perception Runs

Use the deterministic mock/stdout path first when you are checking setup, running headless, or asking an agent to verify the graph:

pixi run demo-webcam-detection-mock

Then use the live webcam path. It tries Rerun first and falls back to stdout when a viewer is not available:

pixi run demo-webcam-detection

Useful variants:

pixi run demo-webcam-detection-mp-rerun
pixi run python -m examples.tutorial.b_ir_and_execution.06_dora_perception \
  --backend in-process \
  --camera-mode mock \
  --visualize stdout \
  --duration 10

Use Rerun when you need to inspect image frames, detections, and timing visually. Use stdout when the question is simply whether the graph runs and emits events.

Record and Replay

pixi run demo-webcam-record
pixi run demo-webcam-replay-rrd

A recorded run gives you a stable artifact for debugging, regression tests, and sharing evidence. The default record command writes logs/perception.rrd plus logs/perception.mcap, then the replay command consumes the recorded events instead of relying on live camera timing.

Practical Triage

Graph looks wrong: render the graph and inspect nodes, ports, clocks, and edge sync policies.
Flow logic looks wrong: use the stepper commands and set breakpoints inside step(...).
Visualization is missing: force --visualize stdout to separate runtime issues from viewer issues.
Behavior changes between runs: record once, then replay the same events.
Backend behavior differs from local stepping: keep the same Pipeline source, compare stepper output with multiprocessing/Rerun output, then inspect the rendered graph for clock or sync-policy differences.

For concrete expected outputs, continue to Examples and Results.
